| Drill depth(m) | 150～80 |
| Borehole diameter(mm) | Ф100～195 |
| Drill pipe power head output speed (forward and reverse) (rpm) | 5～35(Low-end)；5～70() |
| High output torque of drill pipe power head (Nm) | 6000 |
| Output speed (rpm) of casing power head | 10 |
| High output torque of casing power head (Nm) | 12000 |
| Provide progress of power head (mm) | 3500 |
| Power head large lifting force (kN) | 55 |
| Power head large feed force (kN) | 35 |
| Mast sliding stroke (mm) | 850 |
| Mast swing angle(°) | Left 90，right 20；or left 20，right 90 |
| The diameter of the through-hole of the orifice clamp(mm) | 200 |
| Upward turning angle(°) | Left 30，right 90；or right30，lrft 90 |
| Gradeability(°) | 20 |
| Walking speed(kM/h) | 1.2 |
| Power machine power (kW) (Firewood oil engine) | 125 |
| External dimensions of drilling rig (transportation status) (mm) | 約7650x2250x3217 |
| Drill weight(kg) | 約8500 |
| Optional components |
a) 1.1 ton hydraulic winch b) Mud pump c) Wet dust removal device d) Wired remote walking control device e) Safety emergency stop button |
