Product
YG-30 Drilling Rig
  • Product images
  • Product description

  • Introduction The YG-30 engineering drilling rig is suitable for anchoring deep foundation pits in high-rise buildings, water electrical engineering, railway and highway anchoring slope protection, especially for the construction of anchor holes and drainage holes for high slope treatment.

    Main features ● The YG-30 engineering drilling rig is a fully hydraulic driven power head drilling rig. The drilling rig consists of three main parts: the main engine, the control console, and the pump station. Each component adopts flexible connections, with a simple structure and good detachablity, making it easy to install and relocate
    ● The drilling rig is operated centrally through the control panel, ensuring safety and hygiene
    ● The power head is equipped with a variable speed device, with two levels of high and low, to meet the requirements of DTH hammer drilling and hard alloy rotary drilling methods
    ● The hydraulic components of the drilling rig are made of international products, which ensure high reliability and stable performance of the drilling rig

    Technical Parameter
    Drill depth(m) 40-30
    Borehole diameter(mm) ¢80-¢150
    Drill pipe diameter(mm) ¢50×1500¢73×1500
    Drilling angle -90-30°
    Power head output speed (forward and reverse r/min) 24-114
    Power head output torque (N.m) 1500
    Power head stroke (mm) 1800
    Powerhead with high lifting force(KN) 30
    The power head provides high thrust(KN) 15
    Electricity Motivation Power (kW) 15 ModelY160L-4
    Drill weight(kg) 約550
    External dimensions after assembly (mm) 2700×1150×1400
