CG Series Pipe Hammer Machine
- Product images
- Product description
-
-
Overview
With the development of spray anchor support technology for deep foundation pits and soil slopes, our company has developed the CG series hammer pipe machine.
This machine adopts the QCW series down-hole hammer, equipped with air legs and brackets, which can hammer the 30-60mm anchor pipe to the design depth. This machine adopts pneumatic leg support and feeding, which can effectively counteract the counterattack force, reduce labor intensity, and can hammer long anchor pipes to improve hammer pipe speed. Easy to operate, reliable support, and good maneuverability. The carefully designed anchor pipe clamp quickly and reliably grips the anchor rod, effectively transmitting power.
Technical Parameter
|
Model
|
Impactor
|
Air consumptionm/min
|
Pressure MPa
|
Impact energy J
|
|
CG-1
|
QCW80
|
5
|
0.5-0.7
|
≥140
|
|
CG-2
|
QCW100
|
8
|
0.5-0.7
|
≥200
|
|
CG-3
|
QCW150
|
15
|
0.6-0.7
|
≥380
|
